Optical Distribution Box

DATE:2022-10-27   VISITS:87



Features

The distribution box has clamshell splice trays which connected wit adaptor stand to work together.

Impact test: 1K10, tension:100N, completely rugged equipment.

Anti-rust bolts and nuts Fiber bend radius control more than 40mm.


Features

Water-proof design with IP-68 protection level.

Integrated with flap-up splice trays and adaptor holder.

Impact test: IK10,Pull Force:10N,Full rugged design.

All stainless metal plates, anti-rust bolts and nuts. Fiber bend radius control more than 40mm

Suitable for the fusion splice or mechanical splice

1*8 or 1*16 PLC Splitter can be installed in each splice tray as options.

1 mid-span cable entrance(10-16.5mm)for uncut cable and 2 mechanicals glands for distribution cable (8-16.5mm)

3mm glands for flat drop cable(defaulted),7mm glands for round drop cable optional).

24 adaptors for drop cable patching.



Features

Water-proof design withIP-68protection level.

Integrated with flap-up splice trays and adaptor holder.

Impact test: IK10, Pull Force:100N,Full rugged design All stainless metal plate anti-rust bolts and nuts.

Fiber bend radius control more than 40mm.

Suitable for the fusion splice or mechanical splice

1*8 or 1*16 PLC Splitter can be installed in each splice tray as option.

1mid-span cable entrance(10-16.5mm) for uncut cable and 2 mechanicals glands for distribution cable(8-16.5mm).

3mm glands for flat drop cable(defaulted),7mm glands for round dropcable(optional).

24 adaptors for drop cable patching.


Features

Water-proof design with P-68protection level.

Integrated with flap-up splice trays.

Impact test: IK10,pull force:100N,full rugged design.

All stainless metal plateanti-rust bolts and nuts.

Fiber bend radius control more than 40mm. Full mechanical sealing mechanism.

Full rugged design forunder groundpole/wall mounted.

1mid-span cable entrance(10-16.5mm)for uncut cable and 2 mechanicals glands for distribution cable(8-16.5mm) High density capacity max 288 cable splicing.



Features

Water-proof design with IP-68protection level

Integrated with flap-up splice trays.

Impact test: IK10,Pull Force:100NFull rugged design.

Maximum 144F splice capacity,stainless anti-rust bolts and nuts.

Plug-and-playinstallation,easy for maintenance and expansion. Fiber bend radius control more than40mm180 degree access with buckled lock structure.

1*8 or 1*16 PLC splitter can beinstalledin each splice tray as option. Mechanical sealing structure and mid-span cable entry

16 pcs of pre-installed reinforced water-proof adapter for SC1 mid-span cable entrance(10-16.5mm)for uncut cable and 2 mechanicals glands for distribution cable(8-16.5mm)


Features:

Water-proof design with IP-65 protection level.

Integrated with flap-up splice trays.

Maximum 120F splice capacity stainless anti-rust bolts and nuts.

Easy for maintenance and expansion, neat cabling Fiber bend radius control more than 40mm.

180 degree access with buckled lock structure

1*8 or 1*16 PLC splitter can be installed in each splice tray as option.

8 pcs of pre-installed reinforced water-proof adapter for SC

1 mid- span cable entrance (10-16.5mm)for uncut cable and 2 reserved cable entrances for distribution cable gland(8-13.5mm)

Features

Water-proof design with IP-65 protection level.

Integrated with flap-up splice trays and adapter holder.

Maximum 120F splice capacity, stainless anti-rust bolts and nuts.

Easy for maintenance and expansion.

Fiber bend radius control more than 40mm.

180 degree access with buckled lock structure.

1*8 or 1*16 PLC Splitter can be installed in each splice tray as option.

16 pcs of mechanical ports for 3-7mm drop cable

1 mid-span cable entrance(10-16.5mm)for uncut cable and 2 reserved cable entrances for distribution cable gland(8-13.5mm).


Features

Water-proof design with IP-65 protection level.

Integrated with slice trays and three-steps splitter cassettes. Maximum 12F splice capacity stainless anti-rust bolts and nuts Easy for maintenance and expansion

Fiber bend radius control more than 40mm180 degree access with buckled lock structure.

1*8 PLC Splitter can be installed in each splitter cassette24 pcs of mechanical ports for 3-7mm drop cable

1mid-span cable entrance(10-16.5mm)for uncut cable and 2 reserved cable entrances for distribution cable gland(8-13.5mm)


Features

Water-proof design with IP-65 protection level.

Integrated with splice cassette and cable management rods. Manage fibers in a reasonable fiber radius condition.

Easy to maintain and extend the capacity.

Fiber bend radius control more than 40mm.

Suitable for the fusional splice or mechanical splice

1'2 splitter can be installed as an option. Efficient cable management.

1 cable entrance for distribution cable and 2ports for4-7mm drop cable.
